The Future of Smart Glasses
360° panoramic capture. All-day battery life. Privacy-first AI.
Five breakthrough innovations ready for acquisition.
Why ArgusWear Wins
| Feature | Ray-Ban Meta | Snapchat Spectacles | ArgusWear |
|---|---|---|---|
| Battery Life | 4 hours | 3.5 hours | 23+ hours |
| Video Capture | Front-facing only | Front-facing only | 360° Panoramic |
| Gesture Control | No | No | Yes (Patent Pending) |
| Privacy Architecture | Cloud Required | Cloud Required | Local-First AI |
| Wireless Charging | Proprietary Case | Cable Only | Any Qi Pad |
Protected Innovation Portfolio
Five breakthrough innovations with no prior art conflicts
1. Ghost Sensor Architecture
Revolutionary low-power gesture recognition using dedicated sensors separate from main cameras. Enables always-on detection at 95% less power than competitors.
First-to-file advantage secured
2. 360° Temple Configuration
Unique dual ultra-wide camera placement creates true panoramic capture with zero blind spots - a configuration never before patented in smart glasses.
Novel positioning patent
3. Hierarchical Wake System
Multi-tier power management with analog threshold detection - the first implementation in wearable eyewear achieving 23+ hour battery life.
Unique to smart glasses
4. Integrated Power Architecture
Complete system design combining adaptive processing, distributed batteries, and intelligent power routing - demonstrable 6x improvement over existing products.
System-level innovation
5. Universal Wireless Charging
Industry-standard Qi charging integrated into temple design. Works with any wireless charger - no proprietary accessories required.
Cross-industry applicable
Component Validation
All components are commercially available from established suppliers. The OV5693 is the same sensor in Microsoft Surface products. Qualcomm QCC5171 powers current premium earbuds. Every part has been validated in shipping consumer products - this isn't theoretical, it's proven technology in a novel configuration.
Technical Highlights
True 360° Vision
Dual OmniVision OV5693 5MP sensors paired with Sunex DSL382 220° fisheye lenses. Creates seamless panoramic capture with zero blind spots through temple-mounted configuration.
Revolutionary Battery Life
23+ hours typical use through patented power management system. 3+ hours continuous 4K recording. Distributed battery design maintains comfort and balance.
Privacy by Design
All AI processing happens on-device. No cloud dependency for core features. Optional cloud services require explicit opt-in with granular controls.
Invisible Technology
Premium frame design hides all technology. Looks and feels like regular glasses. Titanium and advanced polymer construction.
Ghost Sensor Technology
OV7251 monochrome sensors (3-6mW) handle gesture recognition separately from main cameras. Vesper VM1010 wake microphone draws just 10μA in standby mode.
Efficient Audio System
Knowles balanced armature drivers use 40-60% less power than bone conduction. Directional design prevents sound leakage while maintaining clarity.
Performance Specifications
Camera System
Processing & Audio
Power System
Design
Bill of Materials - Complete Transparency
| Component | Part Number | Qty | Unit Cost | Subtotal |
|---|---|---|---|---|
| Main Camera Sensors | OmniVision OV5693 | 2 | $18 | $36 |
| Ultra-Wide Fisheye Lenses | Sunex DSL382 220° | 2 | $35 | $70 |
| Ghost Sensors | OmniVision OV7251 | 2 | $4 | $8 |
| Main Processor | Qualcomm QCC5171 | 1 | $28 | $28 |
| RAM | 4GB LPDDR4 | 1 | $8 | $8 |
| Storage | 64GB eMMC | 1 | $12 | $12 |
| Speakers | Knowles BA Drivers | 2 | $3 | $6 |
| Microphones | Vesper VM1010 + Knowles SPH0645 | 2 | $2 | $4 |
| Batteries | 125mAh LiPo | 2 | $4 | $8 |
| Wireless Charging | Qi coils + TI BQ51013B | 2 | $4 | $8 |
| Frame & Assembly | Titanium/TR-90 Hybrid | 1 | $35 | $35 |
| Other Components | PCBs, flex cables, sensors | - | $40 | $40 |
| Total BOM (10K units) | $271 | |||
| Total BOM (1M units) | $189 | |||
Power Consumption Analysis
Component Power Draw
| OV5693 Cameras (standby) | 2 × 1mW = 2mW |
| OV5693 Cameras (recording) | 2 × 150mW = 300mW |
| OV7251 Ghost Sensors | 2 × 3mW = 6mW |
| QCC5171 (idle) | 15mW |
| QCC5171 (active) | 200mW |
| Bluetooth 5.3 LE (connected) | 15-30mW |
| Bluetooth (data transfer) | 50-80mW |
| Knowles Speakers | 80-150mW |
| Vesper Wake Mic | 10μA (0.033mW) |
| RAM/Storage (idle) | 5mW |
"All-Day" Smartphone-Style Usage
16-hour active day, charged overnight
| Quick photo/video captures (50x) | 10 min @ 580mW |
| Music streaming (2 hours) | 120 min @ 100mW |
| Notifications (200 checks) | 20 min @ 60mW |
| Voice commands (30x) | 5 min @ 200mW |
| Gesture interactions (100x) | 10 min @ 40mW |
| Standby (13.5 hours) | 810 min @ 28mW |
| Total Energy Used | 610 mWh |
| Battery Capacity | 925 mWh |
| Remaining at Day End | 34% |
Battery: 250mAh (2×125mAh) @ 3.7V = 925mWh total capacity
Smart Connectivity: Bluetooth auto-disconnects when idle, uses BLE advertising mode (50μA).
Wake words or gestures trigger instant reconnection. Phone auto-accepts paired device.
Charge your glasses when you charge your phone, not throughout your day.
Business Case
Key Component Costs
Cameras & Optics:
• OV5693 sensors: $18 × 2 = $36
• Sunex 220° lenses: $35 × 2 = $70
• OV7251 ghost sensors: $4 × 2 = $8
Core Components:
• Qualcomm QCC5171: $28
• 4GB RAM + 64GB storage: $20
• Batteries + Qi charging: $16
• Frame & assembly: $35
Total: $271 @ 10K units → $189 @ 1M units (30% volume discount)
*Continuous recording with automatic phone sync. Onboard storage holds 2.5 hours, seamlessly offloads when connected.
Software Ecosystem
AI-Powered Editing
Automatic highlight detection, smart reframing, and one-tap exports optimized for every social platform.
360° Creative Tools
Professional stabilization, virtual camera movements, and immersive effects previously requiring expensive equipment.
Smart Storage Management
Auto-sync to phone when connected. Intelligent compression. Cloud backup options. Never miss a moment with seamless offloading.
Developer Platform
Open SDK for third-party apps. Computer vision APIs. Gesture recognition framework. Growing ecosystem opportunity.
Enterprise Features
Remote assistance, training capture, safety compliance, and custom deployment options for business customers.
Content Monetization
Built-in tools for creators. Direct platform integration. Analytics and audience insights. Revenue sharing opportunities.
Acquisition Opportunity
What You're Acquiring
Intellectual Property
- ✓ Provisional Patent #63/810,771
- ✓ Five novel hardware innovations
- ✓ Complete system architecture
- ✓ No prior art conflicts identified
Market Position
- ✓ 6x battery life advantage
- ✓ Only 360° smart glasses design
- ✓ Privacy-first architecture
- ✓ Universal charging compatibility
Strategic Value
- ✓ Block competitors from 360° space
- ✓ Cross-license charging innovation
- ✓ Immediate product differentiation
- ✓ Platform for future innovations
Let's Build the Future Together
Protected IP. Proven feasibility. Ready for development.
Full technical documentation, BOM details, and component specifications available under NDA
Matthew N. Kupka | team@arguswear.com
Patent Pending #63/810,771 | Filed May 23, 2025
